Chapter 13 Spanning Tree Protocol
MES-3528 User’s Guide
127
13.4 Configure Rapid Spanning Tree Protocol
Use this screen to configure RSTP settings, see Section 13.1 on page 119 for more
information on RSTP. Click RSTP in the Advanced Application > Spanning
Tree Protocol screen.
Figure 71 Advanced Application > Spanning Tree Protocol > RSTP
The following table describes the labels in this screen.
Table 27 Advanced Application > Spanning Tree Protocol > RSTP
LABEL DESCRIPTION
Status Click Status to display the RSTP Status screen (see Figure 72 on page
129).
Active Select this check box to activate RSTP. Clear this checkbox to disable
RSTP.
Note: You must also activate Rapid Spanning Tree in the
Advanced Application > Spanning Tree Protocol >
Configuration screen to enable RSTP on the Switch.
