Chapter 32 Access Control
MES-3528 User’s Guide
278
32.3.3 SNMP Traps
The Switch sends traps to an SNMP manager when an event occurs. The following
tables outline the SNMP traps by category.
An OID (Object ID) that begins with “1.3.6.1.4.1.890.1.5.8” is defined in private
MIBs. Otherwise, it is a standard MIB OID.
Table 92 SNMP System Traps
OPTION OBJECT LABEL OBJECT ID DESCRIPTION
coldstart coldStart 1.3.6.1.6.3.1.1.5.1 This trap is sent when the
Switch is turned on.
warmstart warmStart 1.3.6.1.6.3.1.1.5.2 This trap is sent when the
Switch restarts.
reset UncontrolledResetEventO
n
1.3.6.1.4.1.890.1.5.8.51.2
7.2.1
This trap is sent when the
Switch automatically resets.
ControlledResetEventOn 1.3.6.1.4.1.890.1.5.8.51.2
7.2.1
This trap is sent when the
Switch resets by an
administrator through a
management interface.
RebootEvent 1.3.6.1.4.1.890.1.5.0.1 This trap is sent when the
Switch reboots by an
administrator through a
management interface.
timesync RTCNotUpdatedEventOn 1.3.6.1.4.1.890.1.5.8.51.2
7.2.1
This trap is sent when the
Switch fails to get the time and
date from a time server.
RTCNotUpdatedEventClea
r
1.3.6.1.4.1.890.1.5.8.51.2
7.2.2
This trap is sent when the
Switch gets the time and date
from a time server.
intrusionlo
ck
IntrusionLockEventOn 1.3.6.1.4.1.890.1.5.8.51.2
7.2.1
This trap is sent when intrusion
lock occurs on a port.
loopguard LoopguardEventOn 1.3.6.1.4.1.890.1.5.8.51.2
7.2.2
This trap is sent when
loopguard shuts down a port.
externalar
m
ExternalAlarmEventOn 1.3.6.1.4.1.890.1.5.8.51.2
7.2.1
This trap is sent when the
external alarm is received.
ExternalAlarmEventClear 1.3.6.1.4.1.890.1.5.8.51.2
7.2.2
This trap is sent when the
external alarm stops sending
an alert.
Table 93 SNMP Interface Traps
OPTION OBJECT LABEL OBJECT ID DESCRIPTION
linkup linkUp 1.3.6.1.6.3.1.1.5.4 This trap is sent when the
Ethernet link is up.
LinkDownEventClear 1.3.6.1.4.1.890.1.5.8.51.27
.2.2
This trap is sent when the
Ethernet link is up.
