![Zyxel MES-3528 [316/354] Viewing the arp table](/views2/1010719/page316/bg13c.png)
Chapter 37 ARP Table
MES-3528 User’s Guide
316
37.2 Viewing the ARP Table
Click Management > ARP Table in the navigation panel to open the following
screen. Use the ARP table to view IP-to-MAC address mapping(s).
Figure 178 Management > ARP Table
The following table describes the labels in this screen.
Table 111 Management > ARP Table
LABEL DESCRIPTION
Index This is the ARP Table entry number.
IP Address This is the learned IP address of a device connected to a Switch port with
corresponding MAC address below.
MAC
Address
This is the MAC address of the device with corresponding IP address above.
Type This shows whether the MAC address is dynamic (learned by the Switch) or
static.
