Chapter 40 Product Specifications
MES-3528 User’s Guide
329
VLAN Port-based VLAN
802.1Q tag-based VLAN
number of VLAN: 4K, 1024 static maximum
GVRP for dynamic registration
Private VLAN for port isolation.
Protocol-Based VLAN.
IP subnet based VLAN
Port
Aggregation
IEEE 802.3ad LACP
Six groups (up to eight ports each)
Port
mirroring
Port-based mirroring
Support port mirroring per IP/TCP/UDP
Bandwidth
control
Supports rate limiting at 64 Kb increments
Provider
Bridge
Layer2 protocol tunneling
Layer 3
Features
IP Capability IPV4 support
64 Management IPs
Routing
protocols
Static Routing
IP services DHCP client
DHCP relay
VLAN-based DHCP relay
DHCP snooping
Filtering Support L2 MAC filtering, L3 IP filtering, Layer 4 TCP/UDP socket
Multicast IGMP snooping (IGMP v1/v2/v3, 16 VLAN maximum-user configurable)
IGMP filtering
MVR
IGMP timer
Multicast reserve group
Static multicast
IGMP snooping fast-leave
IGMP snooping statistics
IGMP throttling
