Zyxel MES-3528 [331/354] Table 116 standards supported continued
![Zyxel MES-3528 [331/354] Table 116 standards supported continued](/views2/1010719/page331/bg14b.png)
Chapter 40 Product Specifications
MES-3528 User’s Guide
331
RFC 2865 RADIUS - Vendor Specific Attribute
RFC 2674 P-BRIDGE-MIB, Q-BRIDGE-MIB
RFC 3046 DHCP Relay
RFC 3164 Syslog
RFC 3376 Internet Group Management Protocol, Version 3
RFC 3414 User-based Security Model (USM) for version 3 of the Simple
Network Management Protocol (SNMP v3)
RFC 3580 RADIUS - Tunnel Protocol Attribute
IEEE 802.1ab Link Layer Discovery Protocol (LLDP)
IEEE 802.1ag Connectivity Fault Management (CFM)
IEEE 802.1x Port Based Network Access Control
IEEE 802.1D MAC Bridges
IEEE 802.1p Traffic Types - Packet Priority
IEEE 802.1Q Tagged VLAN
IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
IEEE 802.3 Packet Format
IEEE 802.3ad Link Aggregation
IEEE 802.3ah Ethernet OAM (Operations, Administration and Maintenance)
IEEE 802.3x Flow Control
Safety UL 60950-1
CSA 60950-1
EN 60950-1
IEC 60950-1
EMC FCC Part 15 (Class A)
CE EMC (Class A)
Table 116 Standards Supported (continued)
STANDARD DESCRIPTION
