Chapter 32 Access Control
MES-3528 User’s Guide
292
Select Accept this certificate permanently to import the Switch’s certificate
into the SSL client.
Figure 163 Security Certificate 1 (Netscape)
Figure 164 Security Certificate 2 (Netscape)
