Chapter 25 IP Source Guard
MES-3528 User’s Guide
220
25.4 DHCP Snooping
Use this screen to look at various statistics about the DHCP snooping database. To
open this screen, click Advanced Application > IP Source Guard > DHCP
Snooping.
Port This field displays the port number in the binding. If this field is
blank, the binding applies to all ports.
Delete Select this, and click Delete to remove the specified entry.
Cancel Click this to clear the Delete check boxes above.
Table 67 IP Source Guard Static Binding (continued)
LABEL DESCRIPTION
