Chapter 23 Multicast
MES-3528 User’s Guide
185
23.3 Multicast Setting
Click Advanced Applications > Multicast > Multicast Setting link to display
the screen as shown. See Section 23.1 on page 183 for more information on
multicasting.
Figure 97 Advanced Application > Multicast > Multicast Setting
Port This field displays the port number that belongs to the multicast group.
Multicast Group This field displays IP multicast group addresses.
Table 51 Advanced Application > Multicast Status (continued)
LABEL DESCRIPTION
