Zyxel MES-3528 [280/354] Table 94 aaa traps continued
![Zyxel MES-3528 [280/354] Table 94 aaa traps continued](/views2/1010719/page280/bg118.png)
Chapter 32 Access Control
MES-3528 User’s Guide
280
accounting RADIUSNotReachableEve
ntOn
1.3.6.1.4.1.890.1.5.8.51.2
7.2.1
This trap is sent when there is
no response message from
the RADIUS accounting
server.
RADIUSNotReachableEve
ntClear
1.3.6.1.4.1.890.1.5.8.51.2
7.2.2
This trap is sent when the
RADIUS accounting server
can be reached.
TACACS+NotReachableEv
entOn
1.3.6.1.4.1.890.1.5.8.51.2
7.2.1
This trap is sent when there is
no response message from
the TACACS+ accounting
server.
TACACS+NotReachableEv
entClear
1.3.6.1.4.1.890.1.5.8.51.2
7.2.2
This trap is sent when the
TACACS+ accounting server
can be reached.
Table 94 AAA Traps (continued)
OPTION OBJECT LABEL OBJECT ID DESCRIPTION
Table 95 SNMP IP Traps
OPTION OBJECT LABEL OBJECT ID DESCRIPTION
ping pingProbeFailed 1.3.6.1.2.1.80.0.
1
This trap is sent when a single ping probe
fails.
pingTestFailed 1.3.6.1.2.1.80.0.
2
This trap is sent when a ping test
(consisting of a series of ping probes)
fails.
pingTestCompleted 1.3.6.1.2.1.80.0.
3
This trap is sent when a ping test is
completed.
traceroute traceRoutePathChange 1.3.6.1.2.1.81.0.
1
This trap is sent when a path to a target
changes.
traceRouteTestFailed 1.3.6.1.2.1.81.0.
2
This trap is sent when a traceroute test
fails.
traceRouteTestCompleted 1.3.6.1.2.1.81.0.
3
This trap is sent when a traceroute test is
completed.
