Chapter 17 Link Aggregation
MES-3528 User’s Guide
153
17.4 Link Aggregation Setting
Click Advanced Application > Link Aggregation > Link Aggregation Setting
to display the screen shown next. See Section 17.1 on page 149 for more
information on link aggregation.
Figure 81 Advanced Application > Link Aggregation > Link Aggregation Setting
The following table describes the labels in this screen.
Table 39 Advanced Application > Link Aggregation > Link Aggregation Setting
LABEL DESCRIPTION
Link
Aggregation
Setting
This is the only screen you need to configure to enable static link
aggregation.
Group ID The field identifies the link aggregation group, that is, one logical link
containing multiple ports.
Active Select this option to activate a trunk group.
