MES-3528 User’s Guide
325
CHAPTER 40
Product Specifications
The following tables summarize the Switch’s hardware and firmware features.
Table 113 Hardware Specifications
SPECIFICATION DESCRIPTION
Dimensions Standard 19” rack mountable
438 mm (W) x 215 mm (D) x 44.45 mm (H)
Weight 3.4 kg
Power Specification DC: -36VDC to -48VDC / 0.8A (max)
AC: 100-240 V AC, 50/60 Hz, 0.34 A Max.
Power Consumption 20 W (maximum)
Interfaces 24 10/100 Base-Tx ports
4 GbE Dual Personality interfaces (Each interface has one
1000Base-T RJ-45 port and one Small Form-Factor Pluggable
(SFP) slot, with one port active at a time.)
Auto-negotiation
Auto-MDIX
One console port
Compliant with IEEE 802.3ad/u/x
Back pressure flow control for half duplex
Flow control for full duplex (IEEE 802.3x)
External signal jack
LEDs Per switch: PWR, SYS, ALM
Per Fast Ethernet RJ-45 10/100 port: LNK/ACT
Per mini-GBIC slot: LNK, ACT
Per 1000BASE-T RJ-45 port (in dual personality interface): LNK/
ACT, FDX
Operating
Environment
Temperature: 0º C ~ 50º C (32º F ~ 122º F)
Humidity: 10 ~ 90% (non-condensing)
Storage Environment Temperature: -10º C ~ 70º C (14º F ~ 158º F)
Humidity: 10 ~ 90% (non-condensing)
Ground Wire Gauge 18 AWG or larger
