Chapter 40 Product Specifications
MES-3528 User’s Guide
328
Port Cloning Use the port cloning feature to copy the settings you configure
on one port to another port or ports.
Syslog The Switch can generate syslog messages and send it to a
syslog server.
Firmware Upgrade Download new firmware (when available) from the ZyXEL web
site and use the web configurator, CLI or an FTP/TFTP tool to
put it on the Switch.
Note: Only upload firmware for your specific model!
Configuration Backup &
Restoration
Make a copy of the Switch’s configuration and put it back on
the Switch later if you decide you want to revert back to an
earlier configuration.
Cluster Management Cluster management (also known as iStacking) allows you to
manage switches through one switch, called the cluster
manager. The switches must be directly connected and be in
the same VLAN group so as to be able to communicate with
one another.
Table 114 Firmware Specifications
FEATURE DESCRIPTION
Table 115 Feature Specifications
Layer 2
Features
Bridging 16K MAC addresses
Static MAC address filtering by source/destination
Broadcast storm control
Static MAC address forwarding
Switching Switching fabric: 12.8 Gbps, non-blocking
Max. Frame size: 9 K bytes
Forwarding frame: IEEE 802.3, IEEE 802.1q, Ethernet II, PPPoE
Prevent the forwarding of corrupted packets
STP IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
Multiple Rapid Spanning Tree capability (2 configurable trees)
IEEE 802.1s Multiple Spanning Tree Protocol
QoS IEEE 802.1p
SPQ, WRR, WFQ, SPQ/WRR or SPQ/WFQ combination capable
Eight priority queues per port
Rule-based bandwidth control (ingress traffic metering/dropping 64Kb
stepping)
Port-based egress traffic shaping
Rule-based traffic mirroring
IGMP snooping
