Chapter 3 Hardware Overview
MES-3528 User’s Guide
34
The following table describes the port labels on the front panel.
3.1.1 Console Port
For local management, you can use a computer with terminal emulation software
configured to the following parameters:
• VT100
• Terminal emulation
• 9600 bps
• No parity, 8 data bits, 1 stop bit
• No flow control
Connect the male 9-pin end of the console cable to the console port of the Switch.
Connect the female end to a serial port (COM1, COM2 or other COM port) of your
computer.
Table 1 Front Panel Connections
LABEL DESCRIPTION
Power
Connection
Connect an appropriate power supply to this port.
For DC, Turn the device on or off using the switch.
24 10/100
Mbps RJ-45
Ethernet
Ports
Connect these ports to a computer, a hub, an Ethernet switch or router.
Four Dual
Personality
Interfaces
Each interface has one 1000BASE-T RJ-45 port and one Small Form-Factor
Pluggable (SFP) slot (also called a mini-GBIC slot), with one port or
transceiver active at a time.
• Four 100/1000 Mbps RJ-45 Ports:
Connect these ports to high-bandwidth backbone network Ethernet
switches using 1000BASE-T compatible Category 5/5e/6 copper cables.
•Four Mini-GBIC Slots:
Use mini-GBIC transceivers in these slots for connections to backbone
Ethernet switches.
Console Port The console port is for local configuration of the Switch.
SIGNAL Connect the signal input pins to signal output terminals on other pieces of
equipment.
Connect the signal output pins to an signal input terminal on another piece
of equipment.
See Chapter 40 on page 325 for details on the pin assignments required.
