Zyxel MES-3528 [237/354] Table 77 arp inspection vlan configure continued
![Zyxel MES-3528 [237/354] Table 77 arp inspection vlan configure continued](/views2/1010719/page237/bged.png)
Chapter 25 IP Source Guard
MES-3528 User’s Guide
237
VID This field displays the VLAN ID of each VLAN in the range specified
above. If you configure the * VLAN, the settings are applied to all
VLANs.
Enabled Select Yes to enable ARP inspection on the VLAN. Select No to disable
ARP inspection on the VLAN.
Log Specify when the Switch generates log messages for receiving ARP
packets from the VLAN.
None: The Switch does not generate any log messages when it
receives an ARP packet from the VLAN.
Deny: The Switch generates log messages when it discards an ARP
packet from the VLAN.
Permit: The Switch generates log messages when it forwards an ARP
packet from the VLAN.
All: The Switch generates log messages every time it receives an ARP
packet from the VLAN.
Apply Click Apply to save your changes to the Switch’s run-time memory.
The Switch loses these changes if it is turned off or loses power, so use
the Save link on the top navigation panel to save your changes to the
non-volatile memory when you are done configuring.
Cancel Click this to reset the values in this screen to their last-saved values.
Table 77 ARP Inspection VLAN Configure (continued)
LABEL DESCRIPTION
