16
7. Lighting
8. Cutting blade
9. Flange washer
10. Fixing bolt for cutting blade
11. Lower guard
12. Cutting depth guide
13. Main handle
14. Battery installation socket
15. Spindle lock button
16. Footplate
17. Knob for base bevel adjustment
18. Cutting line indicator for 45°
19. Cutting line indicator for 0°
20. Edge guide locking screw
21. Battery lock button
22. Battery
23. Charger
24. LED diodes
25. Button for battery level indication
26. Battery level indicator (LED)
27. Cutting depth locking knob
28. Edge guide
*Differences may appear between the product and drawing.
MEANING OF SYMBOLS
CAUTION
WARNING
ASSEMBLY / SETTINGS
INFORMATION
EQUIPMENT AND ACCESSORIES
1. Edge guide - 1 pce
2. Hexagonal key - 1 pce
PREPARATION FOR OPERATION
REMOVING AND INSERTING THE BATTERY
• Push the battery lock button (21) and slide out the battery (22)
(fig. A).
• Insert charged battery (22) into the battery installation socket
(14) in the main handle (13), you should hear when the battery
lock button (21) snaps.
BATTERY CHARGING
The device is supplied with partially charged battery. The battery
should be charged in ambient temperature between 4°C and
40°C. New battery, or one that has not been used for a long
time, will reach full efficiency after approximately 3 to 5 charge/
discharge cycles.
• Remove the battery (22) from the device (fig. A).
• Connect the charger to mains socket (230 V AC).
• Slide the battery (22) into the charger (23) (fig. B). Ensure the
battery is properly fitted (pushed to the end).
When the charger is connected to a mains socket (230 V AC), the
green diode (24) on the charger turns on to indicate connected
supply.
When the battery (22) is placed in the charger (23), the red diode
(24) on the charger turns on to indicate that the charging is in
progress.
At the same time green diodes (26) of the battery level indication
are flashing in different configurations, see description below.
• All diodes are flashing - battery is empty and requires
charging.
• 2 diodes are flashing - the battery is partially discharged.
• 1 diode is flashing - the battery level is high.
Once the battery is charged, the diode (24) on the charger lights
green, and all battery level diodes (26) light continuously. After
some time (approx. 15 s) battery level indication diodes (26) turn
off.
Do not charge the battery for more than 8 hours. Exceeding
this time limit may cause damage to battery cells. The charger
will not turn off automatically when the battery is full. Green
diode on the charger will remain on. Battery level indication
diodes turn off after some time. Disconnect power supply
before removing the battery from the charger socket. Avoid
consecutive short chargings. Do not charge the battery after
short use of the tool. Significant decrease of the period
between chargings indicates the battery is used up and should
be replaced.
Batteries heat up strongly when charging. Do not operate just
after charging – wait for the battery to cool down to room
temperature. It will prevent battery damage.
BATTERY LEVEL INDICATION
The battery is equipped with indication of the battery level (3
LED diodes) (26). To check battery level status, press the switch
button (25) (fig. C). When all diodes are lit, the battery level is
high. When 2 diodes are on, the battery is partially discharged.
When only one diode is lit, the battery is discharged and must
be recharged.
CUTTING DEPTH ADJUSTMENT
Right angle cutting depth can be set from the range of 0 to 46 mm.
• Loosen the cutting depth locking knob (27).
• Set desired cutting depth (use the scale).
• Lock the cutting depth locking knob (27) (g. D).
INSTALLATION OF THE EDGE GUIDE
Edge guide can be installed on left or right side of the device
footplate.
• Loosen the edge guide locking screw (20).
• Slide the edge guide bar into holes in the footplate (16), use the
scale to set required distance and fix by tightening the edge guide
locking screws (20) (g. E).
Edge guide bar should be pointed downwards.
The edge guide (28) can also be used for bevel cutting at angles
ranging from 0° to 45°.
Never put hand or ngers behind the working saw. When kick
back happens the saw can fall on the hand, it may be the cause
of heavy body injury.
MOVING THE LOWER GUARD
Lower guard (11) of the cutting blade (8) is pushed away
automatically as the blade sinks into the material. To remove it
manually push the lower guard lever (5).
DUST EXTRACTION
Circular saw is equipped with dust extraction outlet (1
) that allows
for extraction of sawdust produced when cutting.
OPERATION / SETTINGS
SWITCHING ON / SWITCHING OFF
Hold the saw with both hands when starting up, because engine
torque may cause uncontrolled turn of the power tool.
Remember that rotating parts of the saw rotate for some time
after the tool has been switched o.
