18
• Position new cutting blade so blade teeth and arrow on the blade
match direction of the arrow on the lower guard and upper guard.
• Slide the cutting blade into footplate slot and install on the
spindle so it is well pressed against surface of the inner flange and
centred when seated on its neck.
• Install inner flange washer (9) and tighten the fixing bolt for
cutting blade (10) by turning it clockwise.
• Always put the hexagonal key in its storage place after
replacement of cutting blade.
When installing cutting blade observe correct direction of the
teeth. Arrow on the saw body shows direction of spindle rotation.
Be very careful when holding the cutting blade in hand. Use
protective gloves to provide protection for your hands against
sharp teeth of cutting blade.
All defects should be repaired by service workshop authorized
by the manufacturer.
TECHNICAL PARAMETERS
RATED PARAMETERS
Cordless Circular Saw
Parameter Value
Battery voltage 18 V DC
Rotational speed (no load) 4200 min
-1
Bevel cutting range 0° ÷ 45°
Max. outer diameter of cutting blade 150 mm
Inner diameter of cutting blade 10 mm
Max. cutting
depth
At 90° angle 48 mm
At 45° angle 36 mm
Protection class III
Weight 2,475 kg
Year of production 2017
Graphite Energy+ System Battery
Parameter Value
Battery 58G001 58G004
Battery voltage 18 V DC 18 V DC
Battery type Li-Ion Li-Ion
Battery capacity 2000 mAh 4000 mAh
Ambient temperature range 4
0
C – 40
0
C4
0
C – 40
0
C
Charging time for charger 58G002 1 h 2 h
Weight 0,400 kg 0,650 kg
Year of production 2017 2017
Graphite Energy+ System Charger
Parameter Value
Charger type
58G002
Supply voltage
230 V AC
Power supply frequency
50 Hz
Charging voltage
22 V DC
Max. charging current
2300 mA
Ambient temperature range
4
0
C – 40
0
C
Charging time of the battery 58G001
1 h
Charging time of the battery 58G004
2 h
Protection class
II
Weight
0,300 kg
Year of production
2017
NOISE LEVEL AND VIBRATION PARAMETERS
Noise and vibration information
Parameters of produced noise level, such as sound pressure level
Lp
A
and sound power level Lw
A
with measurement uncertainty K
are specified below in this manual, in compliance with EN 60745.
Vibration values a
h
and measurement uncertainty K are
determined in accordance with EN 60745 and specified below.
Vibration level specified below in this manual was measured in
accordance with measurement procedure defined in EN 60745
and can be used to compare power tools. It can also be used for
initial assessment of exposure to vibrations.
Specified vibration level is representative for main applications
of the power tool. Vibration level may change if the power tool is
used for other purposes, with different working tools or will not
be maintained properly. The abovementioned factors may lead
to higher exposure to vibrations during whole working time.
To precisely define exposure to vibrations, include periods when
the power tool is switched off and when it is switched on but
not used for working. This way total exposure to vibrations may
be significantly lower. Use additional safety measures to protect
the user against results of exposure to vibrations, such as: power
tool and working tool maintenance, proper hand temperature
conditions, good work organisation.
Sound pressure level: Lp
A = 79,2 dB (A) K=3dB (A)
Sound power level: Lw
A =90,2 dB (A) K=3dB (A)
Vibration acceleration value:
a
h
< 2,5 m/s
2
K= 1,5 m/s
2
ENVIRONMENTAL PROTECTION / CE
Electrical equipment must not be disposed off
with household waste and, instead, should be
utilized at appropriate facilities. Information
on utilization can be provided by the product
vendor or the local authorities. Waste electrical
and electronic equipment contains substances
that are not neutral to the natural environment.
Equipment that is not recycled constitutes a
potential hazard to the environment and to
human health.
Li-Ion
Storage batteries/batteries must not be disposed
with domestic waste, put in a fire or into the
water. Damaged or used up storage batteries
must be properly recycled in compliance with the
current directive pertaining to disposal of storage
batteries and batteries.
* Right to introduce changes is reserved.
