GRAPHITE Energy+ 58g008 [17/136] Operation and maintenance

• When the saw is in the place to start cutting, lift the lower

guard (11) with the lower guard lever () (cutting blade is

lifted above the material).

• Switch the power tool on and wait until cutting blade reaches

its full rotational speed.

• Gradually lower the saw and plunge the cutting blade in

material (during this move front edge of the saw footplate

should have contact with surface of the material).

• When the blade starts cutting release the lower guard.

• When whole surface of the saw footplate rests on the material,

move the saw forward to proceed with cutting.

• Never move the saw backwards when the blade is rotating,

there is danger of kick back.

• Finish cutting in reverse order it was started, by turning the

saw around line of contact of the processed material and the

front edge of the tool footplate.

• Before removing blade from the material, allow it to stop after

switching the saw off.

• Finish the corner fillets with reciprocating saw or hand saw

when necessary.

CUTTING OR CUTTING OFF LARGE PIECES OF MATERIAL

When cutting large boards of material support them to avoid

potential blade hitch (kick back) due to pinching the blade in

material kerf.

OPERATION AND MAINTENANCE

Remove the battery from the device before commencing

any activities related to installation, adjustment, repair or

maintenance.

MAINTENANCE AND STORAGE

• Cleaning the device after each use is recommended.

• Do not use water or any other liquid for cleaning.

• Clean the tool with a brush or blow through with compressed air

at low pressure.

• Do not use any cleaning agents or solvents, they may damage

plastic parts.

• Clean ventilation holes in the motor casing regularly to prevent

device overheating. Do not clean ventilation holes by inserting

sharp objects there, such as screwdrivers and other similar objects.

• In case of excessive commutator sparking, have the technical

condition of carbon brushes of the motor checked by a qualiﬁed

person.

• During normal operation cutting blade gets blunt after some

time. When it happens it is necessary to apply greater pressure

when moving the saw during cutting.

• When cutting blade is found damaged, replace it immediately.

• Cutting blade must always be sharp.

• Always store the tool in a dry place, beyond reach of children.

• Store the device with the battery removed.

CUTTING BLADE REPLACEMENT

• Use supplied hexagonal key to unscrew the ﬁxing bolt for cutting

blade (10) by turning it counter-clockwise.

• To prevent rotation of saw spindle, lock the spindle with spindle

lock button (15) when unscrewing the bolt that ﬁxes the cutting

blade (g. K).

• Disassemble outer ﬂange washer (9).

• Use lower guard lever (5) to move lower guard (11) so it hides

maximally in the upper guard (2) (check condition and operation

of the spring that pulls the lower guard at that time).

• Slide the cutting blade (8) out through the slit in the saw footplate

(16).

The device is equipped with the switch, which protects from

accidental starting. The safety switch is located on both sides of the

tool body.

Switching on

• Press one of the switch lock buttons (3) and hold (g. F).

• Press the switch button (2) (g. G).

• You can release the switch lock button (3) after starting the device.

Switching o

• Release pressure on the switch button (4) to stop the tool.

Each time the switch button (4) is pressed, the LED diode (7)

lights up to illuminate the workplace.

CUTTING

Cutting line is deﬁned by the cutting line indicator (18) for 45° angle

or (19) for 0° angle (g. H).

• When starting operation always hold the saw ﬁrmly with both

hands by two handles.

• Switch on the circular saw only when it is away from the material

that is to be cut.

• Do not press the saw too hard. Pressure should be moderate and

continuous.

• After the cut is ﬁnished allow the cutting blade to stop completely.

• If the cutting is aborted before the task is completed, prior to

continuation start the saw and allow for idle operation. Wait until

the tool achieves its full rotational speed and then carefully drive

the cutting blade into the kerf in the processed material.

• When cutting perpendicular to ﬁbres of material (wood), ﬁbres

tend to lift up and tear oﬀ (moving the saw slowly minimizes this

eﬀect).

• Ensure the lower guard reaches its extreme position.

• Before starting to cut always make sure that cutting depth locking

knob and knobs for base bevel adjustment are tightened ﬁrmly.

• With the circular saw use only cutting blades with correct arbour

hole and outer diameter.

• Processed material must be ﬁrmly ﬁxed.

• Place wider part of the saw base on the part of the material, which

is not cut oﬀ.

If the object is small, x the processed material with F-clamps.

If the circular saw footplate does not move on the processed

material, but is lifted instead, there is danger of kick back.

Properly xed processed material and rm hold of the tool ensure

full control over power tool operation. This allows to avoid risk of

body injury. Do not try to hold short pieces of material with your

hand.

FOOTPLATE ADJUSTMENT FOR BEVEL CUTTING

Adjustable saw footplate allows to make a bevel cut in the range

from 0° to 45°.

• Loosen the knob for base bevel adjustment (17) (fig. I).

• Use the scale to set the saw base (16) to appropriate angle

(from 0

to 45

• Tighten the knob for base bevel adjustment (17).

Remember that for bevel cutting the risk of kick back is

greater (pinching of cutting blade more probable), therefore

it is particularly important that the saw footplate rests on the

processed material with its whole surface. Perform cutting with

smooth move.

MAKING A CUT BY PLUNGING INTO MATERIAL

• Set desired cutting depth that matches thickness of material

planned to be cut.

• Tilt the saw so the front edge of the saw footplate (16) rests on

the cut material and 0° marker for perpendicular cutting is in

the line of planned cutting.
