CHAS
FRONT WHEEL
6-1
CHASSIS
FRONT WHEEL
Wheel axle
Speedometer gear unit
Bearing
Spacer
Hub
Rim assembly
Tyre
Oil seal
Spacer
10
Nut
11 Washer
TYRE SIZE:
120/70/12
RIM RUN-OUT LIMIT:
Vertical: 1.0 mm
Lateral: 1.0 mm
WHEEL AXLE BEND LIMIT:
0.25 mm
