Yamaha NEOS 50 YN50 (2002) [19/161] General specifications
![Yamaha NEOS 50 YN50 (2002) [19/161] General specifications](/views2/1121427/page19/bg13.png)
SPEC
GENERAL SPECIFICATIONS
2-2
Model YN50R
Brakes:
Front brake type Disc brake
Operation Right-hand operation
Rear brake type Drum brake
Operation Left-hand operation
Suspension:
Front suspension Telescopic fork
Rear suspension Balancing unit
Shock absorber:
Front shock absorber Spring/oil shock absorber
Rear shock absorber Spring/oil shock absorber
Travel of wheels:
Travel of front wheel 70 mm
Travel of rear wheel 60 mm
Electrical system:
Ignition system DC-C.D.I.
Generating system Magnetic flywheel
Battery type or model YB4C-B
Battery capacity 12V4AH
Type of headlight: Bulb type
Bulb voltage/quantity:
Headlamp 25W/25Wx2
Rear light/brake 5/21W
Indicator 10Wx4
Metre light 1.2Wx2
Warning lights/quantity:
Oil 2Wx1
Fuel 2Wx1
Indicators 2Wx2
