MSI 890FXA-GD70 [49/178] English

MS-7640 Mainboard

English

En-39

MS-7640 Mainboard

English

OC Dial Value

This item indicates the overclocking value by OC dial function. When you rotate the OC

dial knob, this value will change.

OC Dial Adjusted FSB Clock (MHz)

It shows the adjusted FSB clock by OC Dial function (FSB Clock +OC Dial Value).

Read-only.

MEMORY-Z

Press <Enter> to enter the sub-menu.

DIMM1~4 Memory SPD Information

Press <Enter> to enter the sub-menu. The sub-menu displays the information of

installed memory.

Advance DRAM Conguration

Press <Enter> to enter the sub-menu.

DRAM Timing Mode

This eld has the capacity to automatically detect all of the DRAM timing.

1T/2T Memory Timing

This item controls the SDRAM command rate. Select [1T] makes SDRAM signal

controller to run at 1T (T=clock cycles) rate. Selecting [2T] makes SDRAM signal

controller run at 2T rate.

DCT Unganged Mode

This feature is used to Integrate two 64-bit DCTs into a 128-bit interface.

Bank Interleaving

Bank Interleaving is an important parameter for improving overclocking capability of

memory. It allows system to access multiple banks simultaneously.

Power Down Enable

This is a memory power-saving technology. When the system does not access mem-

ory over a period of time, it will automatically reduce the memory power supply.

MemClk Tristate C3/ATLVID

This setting allows you to enable/disable the MemClk Tristating during C3 and

ATLVID.

DDR3 Memory Prole

This item is used to enable/disable the AMD OverDrive

DDR3 Memory Auto-Load

Optimized Prole function. For further information please refer to AMD’s ocial web-

site.

FSB/DRAM Ratio

This item allows you to select the ratio of FSB/ DRAM.

▶
