Application

Prod. No. 36 096:

Single-hole mixer suitable for:

• Direct connection to cold water supply

• Connection to outlet of upstream mixed water supply

Prod. No. 36 095 and 36 097:

Can be used in conjunction with:

• Pressurised storage heaters

• Thermally-controlled instantaneous heaters,

• Hydraulically-controlled instantaneous heaters

Operation with unpressurised storage heaters

(displacement water heaters) is not possible.

Safety notes

• Installation is only possible in frost-free rooms.

• The transformer is only suitable for indoor use.

• In the case of damage to the external transformer

connection cable, this must be replaced by the manufacturer

or his customer service department or an equally qualified

person, in order to prevent a hazard.

• For cleaning purposes, the transformer plug must not be

directly or indirectly sprayed with water.

• The voltage supply must be separately switchable.

• Use only genuine replacement parts and accessories. The

use of other parts will result in voiding of the warranty and

the CE identification.

Technical data

• Flow pressure min. 0.5 bar - recommended 1 - 5 bar

• Operating pressure max. 10 bar

• Test pressure 16 bar

If static pressure exceeds 5 bar,

a pressure-reducing valve must be fitted.

Avoid major pressure differences between

hot and cold water supply.

• Flow rate at 3 bar flow pressure: approx. 6 l/min

• Temperature:

Hot water supply: max. 70 °C

Recommended (energy saving): 60 °C

• Supply voltage (transformer 230 V AC/12 V AC): 230 V

• Power consumption: 3.2 VA

• Automatic safety shut-off

(factory setting): 60 s

• Run-on time (factory setting): 1 s

• Reception range with Kodak Gray Card,

grey side, 8 x 10", landscape, 5cm below

the spout (factory setting): approx. 15cm

• Type of protection: - Fitting IP 59 K

- Transformer IP 44

• Water connection cold - right

hot - left

The test for electromagnetic compatibility (interference

emission test) was performed at the rated voltage and rated

current.

Special accessory

• Infrared remote control (Prod. no. 36 206) for changing the

factory settings and selecting special functions.

Approval and conformity

The conformity declarations can be obtained from the following

address:

GROHE Deutschland Vertriebs GmbH

Zur Porta 9

D-32457 Porta Westfalica

Installation

Flush pipes thoroughly before and after installation

(observe EN 806).

Fitting

Refer to the dimensional drawings on fold-out page I.

Lift rod (A) must be inserted into the mixer body during

installation, see fold-out page II, Fig. [1].

Fasten fitting to wash basin, see Figs. [1] to [3].

Connection

The cold water supply must be connected on the right, hot

water supply on the left.

In order to ensure permanent, trouble-free operation, fitting of

the enclosed adapter is mandatory.

Insert filter (B) and screw adapter (C) together with seal (C1)

onto the service valve, see Fig. [4].

Open hot and cold water supply and check connections

for watertightness.

Connecting the voltage supply

Connect control electronics with plug-in connector (D) to

transformer (E), see Fig. [5].

Connect voltage supply via transformer (E).

Setting the temperature limiter

Prod. No. 36 095 and 36 097:

1. Remove screw (F), see Fig. [6].

2. Turn mixer lever (G) clockwise until the desired maximum

temperature is reached.

3. Detach mixer lever (G), see Fig. [7].

4. Detach stop ring (I) and reattach with notch (I1) pointing

vertically upwards.

5. Turn mixer spindle (H) anti-clockwise to the stop.

6. Attach mixer lever (G) in horizontal position and fasten with

screw (F).

Operation

The infrared electronics emit invisible, pulsed light.

The infrared-electronics are adjusted so that water flow is

initiated when the hands approach the vicinity of the spout.

When the hands are withdrawn from the vicinity of the spout,

water flow is stopped after 1 s (factory setting).

The range of the sensor system is dependent upon the

reflective properties of the detected object.

Automatic safety shut-off

After 60 s (factory setting) of continuous detection of an object,

the infrared electronics automatically stop the water flow.

This product conforms to the requirements of the

relevant EU guidelines.
