DNS-6040M/DNS-6040 User’s Manual
1
Chapter 1
NAS Filer for Business
With the rapid expansion of the net and ever increasing
numbers of Internet users, requirements for storage space are
also exploding. The DNS-6040 Series offers a stable and
efficient storage solution with an easy-to-use interface. Even
non-technical staff will have no trouble installing and
configuring the server.
Specifications
Compatibility: Network Types／ Network File Systems／ Protocols／
Clients
Microsoft network／CIFS, SMB／TCP/IP／ Windows 95, 98, ME, NT 4.0,
2000, XP
UNIX network
／
NFS v2.0 & v3.0
／
TCP/IP
／
Red Hat Linux, Solaris,
FreeBSD
Novell network／ NCP／ IPX／Novell intraNetWare clients for Windows
Apple Macintosh network
／
AFP
／
AppleTalk, TCP/IP
／
Apple Macintosh 7.x,
8.x, 9.x, OS X
Integratable domains
Microsoft NT 4.0 /2000 domain
NIS domain
Software- RAID
RAID 0
RAID 1
RAID 5
RAID 5 with hot spare
