DNS-6040M/DNS-6040 User’s Manual

144

the spare disk will automatically go online and rebuild damaged

data. In other words, you are providing two disks for safety,

leaving you with n-2 disks storage capacity in an array of n

disks.

TIP

Even though RAID greatly increases the level of safety in your system, you

should still make it a habit to back up data periodically. If you accidentally

erase data, even a RAID array cannot restore it. RAID can only compensate

for the failure of one disk, that is, if two disks fail simultaneously, data loss

is inevitable.
