DNS-6040M/DNS-6040 User’s Manual
166
Recipient Subject Email Content
System
Administrator
%HOSTNAME% lost
AC power and is running
on UPS. The system is
going to shut down.
Dear user,
Due to an AC power failure or low
battery of the local/remote UPS,
server %HOSTNAME% was shut
down right after sending this mail.
System
Administrator
%HOSTNAME% lost
AC power and is running
on UPS. The system is
going to shut down.
Dear user,
Due to an AC power failure, power
is temporarily provided by the UPS
system.
Server %HOSTNAME% will be shut
down if the AC power is not
restored within the time specified
on [Toolkit/UPS Management].
System
Administrator
The AC power on server
%HOSTNAME% has
been restored.
Dear user,
The AC power on server
%HOSTNAME% has been
restored.
The shutdown procedure was
cancelled.
System
Administrator
Server %HOSTNAME%:
Low battery of the local
UPS.
Dear user,
The battery of the local UPS is
going to be depleted.
Server %HOSTNAME% will be shut
down immediately.
System
Administrator
The local/remote UPS of
server %HOSTNAME% is
overloaded.
Dear user,
The local/remote UPS of server
%HOSTNAME% is overloaded.
If this situation goes on, server
%HOSTNAME% will be shut down
after the time specified on
[Toolkit/UPS Management].
