DNS-6040M/DNS-6040 User’s Manual
133
Apple clients cannot access the NAS server with the
root
account.
For system administrator root to access the server from an
Apple client, please create another admins group account on the
server.
Apple clients will not be able to save any single file larger than
4GB onto the NAS server. This is due to the limitation of the
system.
Cannot access files in a certain shared folder on the NAS server
via Apple clients.
Check if there is such a shared folder on the NAS server.
Make sure the system administrator has enabled Apple networking
connections over AppleTalk or TCP/IP protocol.
Make sure this account has authorized access to the shared folder.
Check if the account used for logging into the Apple client also has a
same-name account on the NAS server or PDC, and check if the
password is correct.
Make sure that the system administrator does not set a password for
the guest account when users log in as guest.
Check to see if there are any hosts on the network using the same IP or
server name as the NAS server. If there are, correct the situation as
soon as possible.
The DNS-6040 Series will only allow a maximum of 512 clients to
logon to the network at the same time. Users may have to wait a
moment before trying to reconnect.
