DNS-6040M/DNS-6040 User’s Manual
132
map p:=\\NAS001_nw\public1
write login_name
if login_name<>"SUPERVISOR" and
login_name<>"SUPERVIS" and login_name<>"GUEST"
then
map h:=\\NAS001_nw\home
end
As shown in the example, the login script will map the
public1 folder on NAS001 as “p” drive and map users’
home folders on NAS001 as “h” drive for all Novell
clients in the LAN.
Save the “net$log.dat” file to the \SYS\PUBLIC folder on the NAS
server.
Problems about Apple Clients’ Access to the NAS
Server
Cannot find the NAS server via Chooser or Network Browser.
Make sure the NAS server has been turned on and connected in the
LAN.
Check if the Apple client is able to connect with other AppleTalk
servers. If not, the network settings of this Apple client are incorrect.
Make sure the system administrator has enabled Apple networking
connections over AppleTalk or TCP/IP protocol.
