DNS-6040M/DNS-6040 User’s Manual
167
Recipient Subject Email Content
System
Administrator
The capacity of the newly
added hard disk is too
small.
Dear user,
The capacity of the newly added
hard disk is less than those
currently used on the system. It
cannot be utilized for disk
configurations with Raid0, Raid1,
Raid5, or Raid5 with spare.
Please exchange this hard disk for
one with a larger capacity.
System
Administrator
%HOSTNAME% Server
backup successful.
Dear user,
The backup action is completed
successfully.
System
Administrator
%HOSTNAME% Server
restored successfully.
Dear user,
The restore action is completed
successfully.
System
Administrator
%HOSTNAME% Server
backup error, error code
%E.
Dear user,
An error occurred while backing
up.
Please delete the backup file
immediately.
The error code is %E.
System
Administrator
%HOSTNAME% Server
restoration error, error
code %E.
Dear user,
The restore action has failed.
Please check the error code.
The error code is %E.
