D-Link DNS-6040 [121/185] Please note you can run other d link nas data replicator functions only after you have setup nas server and file folders of this machine

DNS-6040M/DNS-6040 User’s Manual

111

 Select those file folders of this computer you wish to backup/monitor

in the tree structure below.

Please note: you can run other D-Link NAS Data

Replicator

functions only after you have setup NAS

server and file folders of this machine.

 Click the Upload button on the right side to display the dialogue

window below:
