DNS-6040M/DNS-6040 User’s Manual
156
Recipient Subject Email Content
order
The %NUM% fan on
%HOSTNAME% is in normal
working order now.
System
Administrator
%NUM% power supply has
failed.
Dear user,
The %NUM% power supply on
%HOSTNAME% has failed.
Please replace the %NUM% power
supply as soon as possible.
System
Administrator
%NUM% battery has been
removed
Dear user,
The %NUM% battery on
%HOSTNAME% has been
removed.
Please confirm and insert a new
battery.
System
Administrator
%HOSTNAME%: %NUM%
battery has failed.
Dear user,
The %NUM% battery on
%HOSTNAME% has failed.
Please replace the %NUM%
battery as soon as possible.
System
Administrator
The disk cage %NUM% on
server %HOSTNAME%
restored to normal
temperature
Dear user,
The disk cage %NUM% on server
%HOSTNAME% has been restored
to normal temperature.
System
Administrator
Overheated Disk cage
%NUM% on server
%HOSTNAME%!
Dear user,
Disk cage %NUM% on server
%HOSTNAME% is excessively hot!
Disk fans might not be working
properly.
Please check the server
immediately and power it down if
necessary!
