DNS-6040M/DNS-6040 User’s Manual
174
Shared Folder Name Case insensitive
≤ 15 characters
The name of a shared folder cannot
exceed 15 characters. The name can be
formed by double-byte character
languages, the same as the language of
the Storage Manager interface,
single-byte languages, numbers, decimal
point, underline and minus sign. The
first character however cannot be minus
sign. The name is not case sensitive.
Group Name Case insensitive
≤ 15 characters
The name of a group cannot exceed 15
characters. The name can be formed by
double-byte character languages, the
same as the language of the Storage
Manager interface, single-byte languages,
numbers, decimal point, underline and
minus sign. The first character however
cannot be minus sign. The name is not
case sensitive.
Toolkit Settings
SNMP Configuration Enable SNMP access
System location
On
Unknown
UPS Management Do not have UPS
Probing Interval
Delayed before shutdown
On
20 seconds
3 minutes
