D-Link DNS-6040 [51/185] Account setup
![D-Link DNS-6040 [51/185] Account setup](/views2/1045689/page51/bg33.png)
DNS-6040M/DNS-6040 User’s Manual
41
TIP
This system software does not support “Telnet”. The system administrator
of the NFS client must use the mount command to point to the NAS server:
mount IP:/Shared_Folder_Path Mount_Point
Whereby IP is the IP address of the NAS server; Shared_Folder_Path is the
folder to be shared with the NFS client, set to /volumen/Shared_Folder_Name
by default, and Mount_Point is set by the UNIX administrator.
E.g., if the system administrator wants to link /user1 to the public1 folder of
the NAS server (i.e. /volume1/public1), and the IP address of the NAS server
is 192.168.1.8, the command would be:
mount 192.168.1.8:/volume1/public1 /user1
Account Setup
The DNS-6040 Series supports up to 512 user accounts
(Including accounts on the local machine, Windows PDC, and
NIS server). Three types of users can access a NAS server:
1. Local users, with an account on the local machine.
2. Users with Windows NT/2000 PDC (Primary Domain
Controller)accounts
3. Users with accounts on a UNIX NIS server
