D-Link DNS-6040 [7/185] Hard disk drive choose warning

vii

BSMI

Danger of explosion if battery is incorrectly replaced. Replace only with the same or

equivalent type recommended by the manufacturer. Dispose of used batteries

according to the manufacturer’s instructions.

Electric shock hazard inside the redundant power supply. The exchange of

modules shall be done by service personnel

Hard Disk Drive Choose Warning

TUV approved Hard Disk Drive is preferred for TUV compliance Hard Disk

drive-Optional, (NWGQ2), generic, four provided, Input Voltage rated 5V dc/1.0A,

12V dc/1.8A maximum, minimum clearance from uninsulated live parts 4.0 mm
