DNS-6040M/DNS-6040 User’s Manual
123
Chapter 7
Troubleshooting
NAS Server Installation Problems
First-time Network Setup with
D-Link NAS Filer Assistant
fails
Make sure you have selected the correct server.
Make sure the server is connected to the LAN. Check the LAN LED
on the server panel to see if the connection is normal.
Make sure the server is connected to a power source and is on.
Make sure the LAN still has free IP addresses.
Make sure the manually entered network settings are correct.
Make sure the client terminal you are using has correctly installed/set
up the TCP/IP protocols, and is running Microsoft Internet Explorer
5.5 or higher.
Make sure the NAS server and the client computer that runs
D-Link
NAS Filer Assistant Utility
can be connected through physical
network medium (e.g. hub, switch, etc.).
Cannot use Internet Explorer to connect to Storage Manager
Check if the network settings of the NAS server are correct and make
sure that the IP of the NAS server does not conflict with those of other
servers in the LAN.
