DNS-6040M/DNS-6040 User’s Manual
155
Recipient Subject Email Content
System
Administrator
%HOSTNAME%
temperature has reached
critical limit!
Dear user,
The server %HOSTNAME%'s
temperature is reaching critical
limit and is going to be shut down
automatically.
After normal temperatures have
been restored, restart the server
and look for the cause of the
problem.
System
Administrator
%HOSTNAME%
temperature restored to
normal
Dear user,
The temperature of the server
%HOSTNAME% has been restored
to normal. Use ToolkitLED
Management on the following site
to reset the LED:
http://%HTTP_URL%/
System
Administrator
A memory error occurred
on %HOSTNAME%
Dear user,
A memory error occurred on
%HOSTNAME%
Memory chips might be faulty.
Please tend to repairs immediately.
System
Administrator
Memory errors occurred
on %HOSTNAME%
Dear user,
Memory errors occurred on
%HOSTNAME%
Memory chips might be faulty.
Please tend to repairs immediately.
System
Administrator
%HOSTNAME%: System
fan has failed.
Dear user,
The system fan on %HOSTNAME%
has failed.
Please replace the system fan as
soon as possible.
System
Administrator
%HOSTNAME%: %NUM%
fan is in normal workin
g
Dear user,
