DNS-6040M/DNS-6040 User’s Manual
97
System information: including server configuration, Security Option,
Apple network setup, Novell network setup, SNMP setup, UPS setup,
etc.
User accounts and groups: including all user accounts, groups, quota
setup, shared folders, Windows domain/workgroup setup, UNIX
network setup. If the NAS server belongs to a Windows domain while
backing up, the Windows domain information (the domain name, PDC
name, and the accounts on the PDC) would also be backed up
simultaneously. Therefore, when restoring back onto the NAS server,
the domain information will also be restored and integrate the NAS
server into this Windows domain.
User accounts, groups, and data: including user accounts, groups,
quota setup, shared folders, Windows domain/workgroup setup, UNIX
network setup, and also the data stored on all shared folders and users’
home folders. If the NAS server belongs to a Windows domain while
backing up, the Windows domain information (the domain name, PDC
name, and the accounts on the PDC), as well as the data Windows
domain accounts stored on the NAS server will be backed up
simultaneously. Therefore, when restoring back onto the NAS server,
the domain information and all domain users’ files will also be
restored and integrate the NAS server into this Windows domain.
All: the configuration and data in the entire server.
Backing up data
Go to
D-Link NAS Backup Utility
, and click on the Backup button to
