DNS-6040M/DNS-6040 User’s Manual
37
added certain Windows PDC user account to Local account or
(2) there is an account in both NAS server and Windows PDC
with the same name, then the User account list on the left will
not show the account number in NT Domain Users but only in
Local Users to prevent system administrator from confusion
caused repeated setup of access rights for the same user.
Deleting User Privileges
To delete user or group privileges, use the mouse to select a
user in the User privileges column (use Ctrl for multiple and
Shift for continuous selection), then click Remove.
TIP
When setting Windows/Novell/Apple user privileges for the
shared folders, make sure to avoid possible conflicts. Root, for example,
is a member of the admins group. To avoid conflicts, you must not set
the privileges for root to read only, while admins is set to writeable.
In the event of conflicts in access privileges, the system will authorize
users/groups in the following order: no access (N/A), readable and
writeable (RW) and read-only (RO). For example, if the access
privilege of the root account (belonging to the admins group) is set as
“N/A” and that of the admins groups is “RW,” the access privilege of
root for this folder will be “N/A.” If the privilege for everyone is set
to writeable and the user root to read only, the system will assign writeable
privileges to everyone as soon as you click Apply.
The DNS-6040 Series
does not support the Windows NT/2000
ACL (Access Control List), i.e. users cannot click the right mouse
button on a file and set the access privilege. The system administrator
can use
Storage Manager
’s Security Setup
Shared Folder Setup page to
set the access privileges for every shared folder.
