DNS-6040M/DNS-6040 User’s Manual
127
volume on it.
The jumpers of the hard disks are set incorrectly. Since jumper settings
depend on the model, refer to the instructions that came with your hard
disk.
The hard disk used to rebuild is of a different type. E.g., if the original
is an ATA 100 model, and you try to use an ATA 66, or a similar
model
from a different manufacturer, the data rebuild may fail. Always use
models from the same maker with similar specifications.
Problems about Windows Clients’ Access to the
NAS Server
Cannot find the NAS server in “Network Neighborhood”
Make sure that the NAS server has been turned on and connected in
the LAN.
Make sure the system administrator has enabled Windows Networking
on the NAS server.
Make sure the Windows client has correctly installed a TCP/IP server.
Enter “My Computer” or “Windows Explorer” and input
“\\Server_Name” in the field of http address.
Start “FindComputer” on the Start Menu, input the name of the NAS
server and search for it.
Click on “ToolsMap Network Drive” in “My Computer” or
