DNS-6040M/DNS-6040 User’s Manual
126
failure of any hard disk in the system will be reported on the
Storage Manager’s Server Information
Status page. A
notification will be sent to the system administrator, who will
only need to remove the broken disk (without having to power
down the system), and replace it with a new one. The system
will automatically configure the new hard disk.
A Simple, Span or RAID 0 volume that has no inherent
safety measures, so that if any hard disk is damaged, all data in
that volume will be lost.
In a RAID 1 or RAID 5 system, if any hard disk is
damaged, after the new hard disk is added, the system will
automatically rebuild the disk and all the data on the volume,
while client access is not compromised during the rebuild phase.
Please note the following:
The replacement disk should be a new and empty disk. Do not insert a
disk with an operating system on it. Furthermore, in the interest of
smooth system operation and better performance, try to use the same
disk model for all disks.
Before inserting the new disk, make sure its jumpers are correctly set.
Hard disk rebuild failure
The following reasons can cause a hard disk rebuilding
operation to fail:
The hard disk used to rebuild is damaged. Try using a brand-new hard
disk.
The hard disk used to rebuild is too small to rebuild the original
