DNS-6040M/DNS-6040 User’s Manual
125
the NIS server is not available. Please make sure the NIS server is
available first and then restart the NAS server.
When purchasing diskless model, please at least one hard disk has to
be installed before booting up the server.
It takes a long time to start the server and it seems to be a boot
failure.
If the NAS server is improperly shut down when it is
operating, the system will automatically check the file system
when the server is restarted, which causes a delay in booting.
The more data are saved on the server, the longer the system
check will take. It probably takes from several minutes to
several hours, and sometimes users tend to regard it as a boot
failure.
If
D-Link NAS Filer Assistant Utility
cannot find the
server after booting or if clients cannot access the NAS server,
check the LED on the server. If the lights under the hard disks
keep blinking, it means that the system is still checking the file
system and the booting has not completed yet. Wait until it
finishes instead of improperly shutting down the server again.
The booting is completed when the LED on the front panel of
the server is back to normal.
Problems about the Hard Disks on the NAS Server
Hard disk failure
The DNS-6040 Series supporting hot-swappable disks, the
