DNS-6040M/DNS-6040 User’s Manual
157
Recipient Subject Email Content
System
Administrator
%HOSTNAME%: %NUM%
battery is in normal
working order.
Dear user,
The %NUM% battery on
%HOSTNAME% is in normal
working order now.
System
Administrator
%HOSTNAME%: %NUM%
system fan is in normal
working order.
Dear user,
The %NUM% system fan on
%HOSTNAME% is in normal
working order now.
System
Administrator
%NUM% battery has been
inserted.
Dear user,
The %NUM% battery on
%HOSTNAME% has been inserted.
System
Administrator
%HOSTNAME%: %NUM%
power supply has
recovered.
Dear user,
The %NUM% power supply on
%HOSTNAME% has recovered.
System
Administrator
%HOSTNAME%:
%DRIVER% %NUM% net
card off line.
Dear user,
%DRIVER% %NUM% net card is
off line.
System
Administrator
%HOSTNAME%:
%DRIVER% %NUM% net
card is on line.
Dear user,
%DRIVER% %NUM% net card is
on line.
System
Administrator
%HOSTNAME% IP Reset
complete
Dear user,
%HOSTNAME% has successfully
reset its IP address.
You can now configure the IP
address of %HOSTNAME%.
System
Administrator
Disk %DISK_ID% on
%HOSTNAME% has
been removed
Dear user,
Disk %DISK_ID% on
%HOSTNAME% has been removed
