DNS-6040M/DNS-6040 User’s Manual

116

Recover files from the server to Windows client

 Select the Restore tab. In the right column is the display of backup

file directory in the NAS Server.

D-Link NAS Data Replicator

default uploads Windows client files to the directory on the NAS

server: \Account_Name\DR BACKUP-client computer name\this

computer. The column on the right displays all subdirectories/files in

each directory.

 Select at the bottom of the page the destination of the restored files.

(Path of your own machine)

 Select files or file folders from the right-hand column, click the right

mouse button, click Restore in the browse function or click the Restore
