DNS-6040M/DNS-6040 User’s Manual
159
Recipient Subject Email Content
System
Administrator
Disk %DISK_ID% of
%HOSTNAME% is
damaged, the spare disk
has been put online
Dear user,
Disk %DISK_ID% of
%HOSTNAME% is damaged.
The spare disk has been put
online. Rebuilding is in progress.
Please locate the source of the
problem and replace the faulty
disk.
System
Administrator
Disk %DISK_ID% on
%HOSTNAME% is
defective
Dear user,
Disk %DISK_ID% on
%HOSTNAME% is defective.
Please tend to the problem and
replace the disk.
System
Administrator
Disk %DISK_ID% on
%HOSTNAME% has an
I/O error.
Dear user,
Disk %DISK_ID% on
%HOSTNAME% has an I/O error.
If this event remains existing, find
out the cause as soon as possible
or replace the hard disk.
System
Administrator
The space of Volume %V
on %HOSTNAME% is
reaching its limit
Dear user,
The space of Volume %V on
%HOSTNAME% is reaching its
limit.
Please remove unnecessary files
or add more disk capacity.
Please reserve at least 10 MB
space on Volume 1 for normal
system operations, otherwise the
system will not be able to run
properly.
Volume %V Total capacity: %G
GB
