DNS-6040M/DNS-6040 User’s Manual
109
accessing data.
D-Link NAS Data Replicator Basic Requirements
5MB Hard Disk Space
Operating System: Windows 98/ME/NT/2000/XP
Optimal Screen Resolution: 800*600 or above
The Windows client running D-Link NAS Data Replicator has
to support Microsoft Networking over TCP/IP protocol, and
can be connected to the NAS server through physical network
medium (e.g. hub, switch, etc.).
Setup D-Link NAS Data Replicator
Please run "Data Replicator.exe" program and install
D-Link
NAS Data Replicator
to your hard disk according to the
instruction given on the screen.
Start Using D-Link NAS Data Replicator
Backup Windows client data to NAS server
First-Time Use - Run Complete Backup
When running
D-Link NAS Data Replicator
the first time,
user must first backup all the files in this machine's file folders
to NAS server before modified/new versions can be monitored.
Start the Backup tab.
