DNS-6040M/DNS-6040 User’s Manual
173
External User
Authentication
Enable Microsoft
network users domain
controller
authentication
Enable UNIX NIS
network
Off
Off
Volume Management
One hard disk in the
first-time installation
Non-RAID volume
(volume1)
Each hard disk with 3 GB
space
Two hard disks in the
first-time installation
RAID 1 volume
(volume1)
Each hard disk with 3 GB
space
Three hard disks or
above in the
first-time installation
RAID 5 volume
(volume1)
Each hard disk with 3 GB
space
Naming Convention
Server Name Case insensitive
≤ 15 characters
May consist of letters, numbers,
underscores, and minus signs
The first character must be a letter
Account Name Case insensitive
≤ 15 characters
The name of an account cannot exceed 15
characters. The name can be formed by
double-byte character languages, the
same as the language of the Storage
Manager interface, single-byte languages,
numbers, decimal point, underline and
minus sign. The first character however
cannot be minus sign. The name is not
case sensitive.
Password Case sensitive
May consist of 0 to 12 displayable
characters
