DNS-6040M/DNS-6040 User’s Manual
158
Recipient Subject Email Content
Please confirm and replace with a
new disk.
Use Server Information on the
following site to check the system
status: http://%HTTP_URL%/.
System
Administrator
Disk %DISK_ID% on
%HOSTNAME% is
initializing.
Dear user,
Disk %DISK_ID% on
%HOSTNAME% is initializing.
Use Server Information on the
following site to check the system
status:
http://%HTTP_URL%/
System
Administrator
Disk %DISK_ID% on
%HOSTNAME% is
rebuilding
Dear user,
Disk %DISK_ID% on
%HOSTNAME% is rebuilding.
Use Server Information on the
following site to check the system
status:
http://%HTTP_URL%/
System
Administrator
Disk %DISK_ID% on
%HOSTNAME% has
been rebuilt.
Dear user,
Disk %DISK_ID% on
%HOSTNAME% has been rebuilt.
Use Server Information on the
following site to check the system
status:
http://%HTTP_URL%/
System
Administrator
Rebuilding of disk
%DISK_ID% on
%HOSTNAME% has
failed
Dear user,
Rebuilding of disk %DISK_ID% on
%HOSTNAME% has failed
Use Server Information on the
following site to check the system
status:
http://%HTTP_URL%/
