DNS-6040M/DNS-6040 User’s Manual
152
Appendix 5
Novell access to the NAS server
A Windows client terminal must have Client Service for
Netware or Novell Client for Windows installed before access to
the NAS server’s Novell service (this server only offers Binding
Service, and no NDS).
Suppose you wish to access the server NAS001 from a client
with Client Service for Netware installed. In the Windows
Network Neighborhood, you will find an entry Netware or
compatible networks with the entry NAS001_NW inside. Enter
your name and password, or log in as guest. All the data for
which access privileges exist will be visible. Users who are part
of the users group (see chapter 4) will find their own home
folders.
From a terminal running Novell Client for Windows, you can log
in with the binding server. In Client 4.8 for Windows NT/2000,
select Network Neighborhood
Entire Network
Netware
Services
Netware Servers. Here you will find the entry
NAS001. The remainder of the login procedure is the same as
for Client Service for Netware.
To access storage space on the NAS001 from a Windows client,
access the drive through Network Neighborhood, or create a
permanent link to the drive on NAS001 in the client’s file
manager.
Note:
