DNS-6040M/DNS-6040 User’s Manual
145
Appendix 2
Windows access to the NAS server
After installing the NAS server (we shall assume the default
server name NAS001), the server NAS001 will appear in
Windows Network Neighborhood. Users with access to NAS001
who are members of the users group (see Security Setup
section
above) can access a folder named after their account and other
folders to which they have access on NAS001.
To access storage space on the NAS001 server from a Windows
client, access the drive through Network Neighborhood, or
create a permanent link (map network drive) to the drive on
NAS001 in the client’s file manager.
Windows NT 4.0/2000 users accessing the NAS server will be
prompted for their account and password when accessing the
NAS server.
When Windows 95/98 clients try to access the server, the
Windows operating system will read the login name of the client
and prompt the user to enter only the correct password. If the
account information on the NAS server does not match the
client’s login name, access will be denied. Therefore, if the
client terminal runs Windows 95 or 98, please use the same
names for accounts on this server and the clients.
