D-Link DNS-6040 [110/185] Restoring data back onto the server

DNS-6040M/DNS-6040 User’s Manual

100

automatically divide the backup file into several

4GB-size files, and name the extension of each file in

the order of “.bkp”, “.001”, “.002”, etc. Please store

these files in the same directory. When restoring the

data back onto the NAS server in the future, the

administrator only needs to specify the “.bkp” file,

and other related files will also be restored

automatically without manually restoring every single

file.

Restoring data back onto the server

 Go to D-Link NAS Filer Restore, and click on the Restore button to

open the backup window.
