DNS-6040M/DNS-6040 User’s Manual
99
Example 1:
The system administrator has backed up all the
data from the server to a “Data 0101.bkp” file, at
12:00 noon on January 1. To make another backup at
11:00 (before 12:00 noon) on January 5, the
administrator could only backup the changes of the
past 4
days to another file called “Data
0101_0105.bkp”.
Example 2:
The system administrator has backed up all the
data from the server to a “Data 0101.bkp” file, at
12:00 noon on January 1. To make another backup at
17:00 (after 12:00 noon) on January 5, the
administrator could only back up the changes of the
past
5
days to another file called
“Data0101_0105.bkp”, in order to complete the
backup of all changes.
Click Apply. The system starts to back up. After the backup is
complete, click on Report to review the back up report.
Note:
FAT/FAT32 does not support files larger than 4GB.
When running
D-Link NAS Filer Backup
on
Win95/98 clients with FAT/FAT32, or backing up files
from the NAS server to another devices running
Win95/98 with FAT/FAT32, the system will
