DNS-6040M/DNS-6040 User’s Manual
11
Input “System administrator password”. The first time a password is
requested, enter the default password; if none exists leave this field
blank.
Click “Apply” to confirm. The program will automatically invoke
the browser and connect to the server’s IP address, then start the
“Quick Configuration” option of
Storage Manager
(see chapter 3).
TIP
DHCP (Dynamic Host Configuration Protocol) is a network protocol for
automatic IP assignment. If your network does not include a DHCP
server, you must enter the network configuration manually.
If the search or configuration fails, please verify the
following details before trying again:
1. Make sure you have selected the correct server.
2. Make sure the server is connected to the LAN. Please make sure that
the network status displayed by the LAN LED on the panel of the
server is normal.
3. Make sure the server is connected to a power source and is turned on.
4. Make sure the LAN still has free IP addresses.
5. Make sure the manually entered network settings are correct.
6. Make sure the client terminal you are using has successfully
installed/set the TCP/IP protocol, and is running Microsoft Internet
Explorer 5.0 or higher.
7. Make sure the NAS server and the client computer that runs
D-Link
NAS Filer Assistant Utility can be connected through physical
network medium (e.g. hub, switch, etc.).
